| Bios________________________________ | |||
| Version | Descriptif | Date | DL |
| 4.20c beta | Add setup item "C.A.M. (Clever Access Memory)" | 01/04/21 |  |
| 4.20b beta | Add setup item "C.A.M. (Clever Access Memory)" | 22/03/21 | |
| 4.20 | Update Intel Microcode and ME | 01/11/19 | |
| 4.10 | Update Intel Microcode and ME *User will not able to flash to previous BIOS once upgrading to this BIOS version. **We don't recommend users to update the BIOS if their system is already running normally. |
11/06/19 | |
| 4.00 | Update Intel Microcode *User will not able to flash to previous BIOS once upgrading to this BIOS version. **We don't recommend users to update the BIOS if their system is already running normally. |
15/04/19 | |
| 3.30 | 1.Update Intel Microcode, ME, RAID ROM 2.Improve memory compatibility 3.Adjust the ""Above 4G Decoding"option. |
28/11/18 | |
| 3.20 | Update Intel Microcode | 11/10/18 | |
| 3.10 | 1.Update Intel ME 11.8.50.3470 2.Update VBIOS to 1059 3.Support the latest Intel 8th Gen CPU |
10/07/18 | |
| 1.80 | Improve memory compatibility. | 26/03/18 | |
| 1.61 beta | CPU TDP watts reading correction. | 06/03/18 | |
| 1.60 | Update CPU Microcode to revision 84. (For CPU security update) | 02/03/18 | |
| 1.40 | 1. Update CPU Microcode to revision 80. 2. Improve memory compatibility. |
12/01/18 | |
| 1.30 | 1.Update Intel ME 11.8.50.3425. 2.Enhance CPU performance. |
30/11/17 | |
| 1.20 | Enhance SATA compatibility | 03/11/17 | |
| 1.10 | Fix the Vcore drop issue with load-line calibration setting. | 16/10/17 | |
| 1.00 | Release | 03/10/17 | |
| Drivers____________________________________ |
|||||
| 📣 For optimal stability and performance under Windows, please regularly update your drivers below | |||||
| 💿CHIPSET | Intel Chipset Device Software For Chipsets Series 300 (Coffee Lake) 8/9e gen(Forum Intel💬) | 24/02/25 | |||
| WINDOWS 7 | WINDOWS 10 | Version 10.1.20062.8627 | |||
| WINDOWS 8.x | WINDOWS 11 | Version 10.1.20062.8627 | |||
| FIRMWARES | WINDOWS 12 | ||||
| 💿GPU | Intel Xe UHD Graphics for Chipsets Series 300 (Coffee Lake) 8/9 gen | 29/03/25 | |||
| WINDOWS 7 | WINDOWS 10 | Version 31.0.101.2135 | |||
| WINDOWS 8.x | WINDOWS 11 | Version 31.0.101.2135 | |||
| 💿CHIPSET | Intel Management Engine Interface For Chipsets Series 300 (Coffee Lake) 8/9 gen | 08/01/25 | |||
| WINDOWS 7 | WINDOWS 10 | Version 2451.7.6.0 | |||
| WINDOW 8.x | WINDOWS 11 | Version 2451.7.6.0 | |||
| FIRMWARE | Version 11.8.96.4657* | WINDOWS 12 | |||
| 💿SATA/RAID | Intel Rapid Storage Technology (RST) For Chipsets Series 300 (Coffee Lake) 8/9gen | 23/05/21 | |||
| WINDOWS 7 | WINDOWS 10 | Version 17.9.6.1019 | |||
| WINDOWS 8.x | Version 17.9.6.1019 | WINDOWS 11 | Version 17.9.6.1019 | ||
| FIRMWARES | WINDOWS 12 | ||||
| 💿SATA/RAID | Asmedia ASM-106x Sata/Raid controllers | 06/03/25 | |||
| WINDOWS 7 | Version 3.3.5.0 | WINDOWS 10 | Version 3.3.5.0 | ||
| WINDOWS 8.x | Version 3.3.5.0 | WINDOWS 11 | Version 3.3.5.0 | ||
| FIRMWARES | WINDOWS 12 | ||||
| 💿LAN | Intel Lan Controllers I219-V, I219-LM, I219 ..... (1Gbps)(Forum Intel💬) | 18/03/25 | |||
| WINDOWS 7 | WINDOWS 10 | Version 12.19.2.62 | |||
| WINDOWS 8.x | WINDOWS 11 | Version 20.0.3.6* | |||
| 💿USB | Asmedia ASM-2142 USB 3.1 Controller | 07/11/20 | |||
| WINDOWS 7 | Version 1.16.61.1 | WINDOWS 10 | Version 1.16.61.1 | ||
| WINDOWS 8.x | Version 1.16.61.1 | WINDOWS 11 | Version 1.16.61.1 | ||
| FIRMWARES | 230802_70_02_40 | WINDOWS 12 | |||
| 💿LAN/WLAN | Intel I210, I211, ... Gigabyte Ethernet (1Gbe) Controllers(Forum Intel💬) | 01/05/25 | |||
| WINDOWS 7 | WINDOWS 10 | Version 14.1.5.0 (30.1) | |||
| WINDOWS 8.x | WINDOWS 11 | Version 14.1.5.0 (30.1) | |||
| 💿AUDIO | Realtek Generic drivers (HDA) or Manufacturer (UAD) (Msi )(Forum Realtek💬) | 26/04//25 | |||
| WINDOWS 7 | Version 6.0.9239.1 (HDA) | WINDOWS 10 |
Version 6.0.9239.1 (HDA) | ||
| WINDOWS 8.x | Version 6.0.9239.1 (HDA) | Version 6.0.9788.1 (UAD) | |||
| UTILITIES | Realtek Audio Console (UWP) | WINDOWS 11 |
Version 6.0.9239.1 (HDA) | ||
| FIRMWARES | Version 6.0.9788.1 (UAD) | ||||
