Intel(R) Wireless WiFi/Bluetooth drivers v23.x.x.x

Yeah i have an AX411 in one of my pc's so already knew what 0033 was

Im trying to find out what 0037 + 0038 is

Intel(R) Dual Band Wireless-AC 7260
USB\VID_8087&PID_07DC
Intel(R) Dual Band Wireless-AC 7265
USB\VID_8087&PID_0A2A
Intel(R) Wireless-AC 9260 160MHz
USB\VID_8087&PID_0025&REV_0001
USB\VID_8087&PID_0025&REV_0002
Intel(R) Wireless-AC 9560 160MHz
USB\VID_8087&PID_0AAA&REV_0000
USB\VID_8087&PID_0AAA&REV_0001
USB\VID_8087&PID_0AAA&REV_0002
Intel(R) Wi-Fi 6 AX200 160MHz
USB\VID_8087&PID_0029&REV_0000
USB\VID_8087&PID_0029&REV_0001
Intel(R) Wi-Fi 6 AX201 160MHz
USB\VID_8087&PID_0026&REV_0000
USB\VID_8087&PID_0026&REV_0001
USB\VID_8087&PID_0026&REV_0002
Intel(R) Wi-Fi 6E AX210 160MHz
USB\VID_8087&PID_0032&REV_0000
Intel(R) Wi-Fi 6E AX211 160MHz
Intel(R) Wi-Fi 6E AX411 160MHz
USB\VID_8087&PID_0033&REV_0000
USB\VID_8087&PID_0033&REV_0001
Intel(R) Wi-Fi 7 BE200 320MHz
USB\VID_8087&PID_0036&REV_0000
USB\VID_8087&PID_0036&REV_0001
Intel(R) Wi-Fi 7 BE201 320MHz?
USB\VID_8087&PID_0037&REV_0000
USB\VID_8087&PID_0037&REV_0001
Intel(R) Wi-Fi 7 BE202 160MHz?
USB\VID_8087&PID_0038&REV_0000
USB\VID_8087&PID_0038&REV_0001

STP = Intel(R) Dual Band Wireless-AC 7265
THP = Intel(R) Wireless-AC 9260 160MHz
JFP = Intel(R) Wireless-AC 9560 160MHz
CCP = Intel(R) Wi-Fi 6 AX200 160MHz
HRP = Intel(R) Wi-Fi 6 AX201 160MHz
TYP = Intel(R) Wi-Fi 6E AX210 160MHz
GFP = Intel(R) Wi-Fi 6E AX211/AX411 160MHz
GAP = Intel(R) Wi-Fi 7 BE200 320MHz
??? = Intel(R) Wi-Fi 7 BE201 320MHz?
MTP = Intel(R) Wi-Fi 7 BE202 160MHz?

0036, 0037, 0038 for new model WiFi-7 BE 200 (320MHz), BE 201 (320MHz, CNVio only), BE 202 (160MHz)
0037 BE 201 FMP "Filmore Peak"

Its getting a chore remembering what card is in what pc..

Dell Vostro 3750 i3 2350M
Intel(R) Dual Band Wireless-AC 7260
Dell Vostro 3750 i7 2820QM
Intel(R) Wi-Fi 6 AX200 160MHz
Fujitsu Lifebook A555 i5 5200U
Intel(R) Dual Band Wireless-AC 7265
Z390 M Gaming i7 8700K
Intel(R) Wi-Fi 6 AX200 160MHz
HP Zbook Power G8 i9 11950H
Intel(R) Wi-Fi 6 AX201 160MHz (Soldered)
Firebat T8 Plus Intel N100
Intel(R) Wi-Fi 6E AX210 160MHz
Z690 Aorus Master i9 12900K
Intel(R) Wi-Fi 6E AX210 160MHz
Z690 Aorus Elite AX DDR4 Upstairs i9 12900K
Intel(R) Wi-Fi 6E AX411 160MHz
Z690 Aorus Elite AX DDR4 Downstairs 19 13900K
Intel(R) Wi-Fi 7 BE200 320MHz
Z390 Aorus Master i9 9900K
Intel(R) Wi-Fi 7 BE200 320MHz

Im tempted to pickup a few more BE200's and upgrade the ones that can be upgraded






Intel just limiting or locking Wi-Fi features through driver level. I have managed to make a AX210/AX211 to be a AX411 with all kind of features like DCT & NetAdapterCx driver support...

www.techpowerup.com/forums/threads/teste...11-wifi-chip.325408/

Already works on my AX211 which is basically a AX411. They share the same HW spec.... Same thing applies for AX1650 I upgraded the driver to be a AX1690 bec. they also share the HW spec...

It's just Intel locking down features through driver level to force you to buy the new WiFi chip/cards.

Shonk 寫了道：:

Yeah i have an AX411 in one of my pc's so already knew what 0033 was

Im trying to find out what 0037 + 0038 is

Intel(R) Wi-Fi 7 BE201 320MHz?
USB\VID_8087&PID_0037&REV_0000
USB\VID_8087&PID_0037&REV_0001
Intel(R) Wi-Fi 7 BE202 160MHz?
USB\VID_8087&PID_0038&REV_0000
USB\VID_8087&PID_0038&REV_0001

??? = Intel(R) Wi-Fi 7 BE201 320MHz?
MTP = Intel(R) Wi-Fi 7 BE202 160MHz?


I have a  reference in the WiFi 23.70.3.1 driver for BE202 as MTP ,and the BE201 is listed as FMP.

Cheers
Tom
